KU-6 Truck Specs – View/Download PDF


Features & Highlights

RF PACKAGE

  • Antenna : 2.4m AVL, Interchangeable C or KU, Multiple feeds on same polarity, Downlink multiple signals on either polarity
  • SSPA/Amp : 300w Paradise Datacom SSPA and 450w ETM
  • Encoders : Ateme or Adtec. MPEG-2/4, DVB-S/2, Q/8PSK

VIDEO

  • Router : 16×16 Leitch/Harris HD/SD multi-format
  • Monitoring : Multi-viewer
  • DAs : Miranda HD/SD re-clocking, re-EQing DA’s
  • Conversions : AJA FS1 frame sync/converter (up, down, cross, embed, de-embed)

AUDIO

  • Mix/Monitoring : 16 channel analog, AES, embedded and decoding of Dolby-E surround sound

COMMS/IFB

  • Three phone interfaces for any combination of IFB/PL dial-ups, Talent interrupt on either or both IFB channels

NET RETURN

  • DSS Receiver

CABLE

  • Truck carries at least 500’ of fiber and coax

INTERNET

  • EVDO wireless internet access

POWER REQUIREMENTS :

  • SHORE 100 AMP SINGLE PHASE, 220 VOLTS
  • 150’ OF SHORE POWER CABLE ON BOARD WITH STANDARD CAMLOCK OR PIGTAIL
  • ON-BOARD POWER TECH 10 DIESEL GENERATOR

SPACE REQUIREMENTS :

  • 12’3” H (ADD 8.5’ FOR ANTENNA), 8’ W (ADD 3’ FOR DOOR), 27’ 10” L
  • WEIGHT 20,000 POUNDS
  • DODGE RAM 5500 DIESEL
